Granville Knotty Hickory Shaker Cabinets

Shaker

American Hickory

3/4" Solid American Hickory

American Hickory

American Hickory

3"

Yes

1/2" solid hickory

1/2" solid hickory

1/2" solid hickory

1/2" plywood

3/4" adjustable shelves

12"

Solid slab

3/4" solid wood dovetail

Undermount, soft close

Metal bracket reinforced corners

Full

Soft close, 6-way adjustable, concealed

Natural box, shelves and drawers (will not have knots like the exterior)

Natural hickory

Cabinets 39" and wider will have center stiles, these cabinets do not have butt doors.

Screw & Glue

Baked on UV Finish

1/2" thick

3/4" plywood

Yes

Hinged right by default, doors can be flipped for a left hinge orientation (hinge holes may need to be drilled onsite) *please note that certain base cabinets can be selected as left or right hinge, these are replacing the universal base cabinets, during this transition period, if a left or right is selected and isn't available yet, a universal base would be sent which can be hinged, on site, after delivery*

Natural (skins will be needed to match the knotty look on exposed cabinet sides)

Knots and wood variations create a distinct look and are not considered defects. Scribe needs to be used for a wall cabinet against a wall or deeper cabinet/appliance. For base cabinets, a 1/2" space needs to be left (which can be filled with a filler that is cut to size). The cabinet depth measurement listed is the depth from the front of the face frame to the back of the cabinet, and does not include the cabinet door depth. Cabinet specs are subject to change without notice. *Cabinet measurements are typically converted from metric to inches and manufacturers will commonly round up to the nearest 1/4 inch. This can cause a measurement to be off by a fraction of an inch (less than 1/4") which is within normal industry standards.* Schematic images and renderings are generic and may not represent exact construction details for each collection. The exact specifications for this collection can be found in the construction details listed above.
