Brookside Harbor Shaker Cabinets

Shaker

Five-piece painted HDF door with mortise and tenon frame, rounded inside bevel and flat recessed center panel

2-3/4"

3/16"

Full Overlay Doors & Drawers

Furniture grade 1/2" plywood box with full back and solid hardwood frame

UV coated matching exterior

5/8" dovetail drawer box with fully captured bottom

Full extension undermount soft-close glides

6-way adjustable hinges with soft-close feature

UV coated natural interior

Glue & staple or metal clip assembly

Yes (CARB2)

Doors come pre-drilled for the hinges, the face frame has marks where to drill, and the customer chooses Right or Left during assembly.

Yes

The full-overlay door style leaves roughly a 1/4" clearance on the edge. If installed directly against a wall or deeper cabinet and a cabinet door opening of at least 90 degrees is desired, scribe molding should be installed between the cabinet and the wall (or deeper cabinet). If not, the door may not be able to open a full 90 degrees. For a full opening, a space of at least 1/4-1/2" is necessary, and a larger space may be needed depending on the decorative hardware used on the cabinets. The cabinet depth measurement listed is the depth from the front of the face frame to the back of the cabinet, and does not include the cabinet door depth. Cabinet specs are subject to change without notice. *Cabinet measurements are typically converted from metric to inches and manufacturers will commonly round up to the nearest 1/4 inch. This can cause a measurement to be off by a fraction of an inch (less than 1/4") which is within normal industry standards.* Schematic images and renderings are generic and may not represent exact construction details for each collection. The exact specifications for this collection can be found in the construction details listed above.
